EAR99, CCL, ECCN, and more: tips and checks for US export controls

An overview of US export controls, from EAR99, CCL, and CCC to ECCN. Because violations of US re-export control law can have serious consequences.

When companies are subject to US re-export control law under the EAR

Under the EAR (Export Administration Regulations), the United States claims extraterritorial jurisdiction for its export controls – currently the only country to do so. Which is why companies based outside the US also have to deal with US re-export control regulations under the EAR when trading in civilian US items.

The extraterritoriality follows from the concept of re-export, which means that shipments outside the US also fall within the scope of the EAR. EAR § 734.14 defines a re-export under EAR as follows:

§ 734.14 RE-EXPORT
(…)
(1) An actual shipment or transmission of an item subject to the EAR from one foreign country to another foreign country, [...]
(…)

Although the EAR applies to all countries worldwide, extraterritorial application is limited to “items subject to the EAR.” Before beginning with comprehensive EAR screening, it’s best to first check which business transactions have any link to the US and thus fall within the scope of the EAR. The EAR cites two scenarios as possible links:

  1. Item-based applicability of all US items worldwide (§ 734.3/4/9)
  2. Person-based applicability for certain activities of US persons (§ 734.5)

EAR: Does the product master include US items?

All US civilian products worldwide fall within the scope of US re-export control under the EAR. The definitive list of such products can be found in § 734.3/4/9 EAR. This means that all companies outside the US must first determine whether their product master includes any US items.

Products that are located in the US

Under § 734.3(a) 1 EAR, all civilian products located in the US fall within the scope of the EAR. This also applies to goods transiting the US.

Example (§ 734.3(a) 1 EAR)

Products manufactured in Germany are shipped through the Port of Miami to Central or South America. In Miami, the products are merely repackaged. The German products are then subject to the EAR as US items when exported from the US. Once they leave the US, the products are no longer within the scope of the EAR, so their attribute as “US item” is lost.

Products that were manufactured in the US

Under § 734.3(a)(2) EAR, all civilian products manufactured or significantly modified in the US and not assigned to another authority are US items within the scope of the EAR. This is the most common scenario of extraterritorial application of the EAR. No matter where in the world the US-origin products are located, they are subject to the provisions of US re-export control under the EAR.

Example (§ 734.3(a)(2) EAR)

Pumps that were manufactured in the US and are found in the product master of a German company fall within the scope of the EAR as US-origin products. If these pumps are shipped from Germany to South Africa and from there to Sudan, both the delivery from Germany to South Africa and the onward delivery to Sudan are re-exports within the scope of the EAR.

Products that include US items

Under § 734.4 EAR, products manufactured outside of the US are considered US items if they contain a certain percentage of controlled US items (“de minimis" rule). The decisive factor for application of the de minimis rule is whether the installed US items are controlled for the country of destination of the product manufactured outside the US.

A US item is considered “controlled” if its export from the US to the destination of the product manufactured in Germany, for example, is subject to licensing requirements under the EAR.The de minimis threshold for controlled US items is generally 25%.

An exception is made for the countries in country groups E:1 and E:2 (currently Iran, Cuba, Syria, and North Korea): Here, the threshold is 10% (see § 734.4 EAR).

Example (§ 734.4 EAR)

A company purchases non-listed, EAR99-classified standardized pumps from the US. The pumps are installed in German machines. The German machines are destined for South Africa. A calculation of the US content of the pumps under the de minimis rule is needed only if the US pumps are subject to licensing requirements under the EAR when destined for South Africa.

To determine this, run the following fictitious test:

  • If the US pumps (EAR99) were delivered to South Africa without being installed, this could be done without a license. The re-export of US pumps (EAR99) to South Africa is not subject to licensing requirements. The US pumps (EAR99) are not controlled for South Africa.
  • If the US pumps are installed in a German machine and delivered to South Africa, the controlled US share is 0%. It’s important to understand that the de minimis rule depends on the controlled US percentage and not on the actual percentage. Even if the US pumps account for 37% of the actual sales price of the German machine, the decisive 0% of controlled US content remains relevant for the de minimis rule.

The results of the test are as follows: The German machines are not US items for South Africa and therefore not subject to the EAR.

  • If the final destination of the German machinery were Syria, the results of the test would be different. Exports of all US items to Syria are subject to licensing requirements. This means that the US pumps for the destination of Syria are controlled. The controlled US portion for Syria is 37% – above the de minimis threshold of 10% applicable to Syria.

The results of the test are then as follows: The machines are US items for Syria and therefore subject to the EAR.

The guidelines for applying the de minimis rule can be found in Supplement No. 2 to Part 734 EAR. Before companies can start calculating the US percentage as part of a de minimis calculation, the following information must be available:

  • Classification of installed US items: ECCN or EAR99
  • Destinations of products manufactured outside the US
  • Combinations of goods and countries subject to licensing requirements under the EAR

A de minimis calculation – that is, a percentage calculation – is required only for the installed US items subject to licensing requirements for the specific destinations. A number of exceptions to the de minimis rule can be found in § 734.4(a)(1)–(5) and elsewhere. Special terms apply to ECCN 9x515 and the 600 series.

Products manufactured under US license

Products manufactured outside the US fall under the scope of the EAR as “foreign direct products” (FDP) in accordance with § 734.9 EAR if they were manufactured directly using certain US technology or US software.

Products manufactured outside the US are also considered FDP under the EAR if manufactured using production facilities that themselves are the direct product of certain US technology or US software. In § 734.9, the EAR outlines nine distinct scenarios in which the FDP rules apply.

Example (§ 734.9 EAR)

A German company uses a US license (US technology: EAR99) to manufacture non-listed pumps (EAR99). The pumps manufactured in Germany using non-listed US technology do not fall under the scenarios for applying the FDP rules described in § 734.9 EAR.

The results of the test are as follows: The pumps manufactured in Germany under a US license are not US items subject to the EAR.

EAR: Are US persons involved?

In addition to those provisions that define applicability by item, § 734.5 EAR defines it by person – specifically, activities of US persons. This is why companies should take the additional step of checking whether they are within the scope of the EAR based on the activities of US persons. The term “US person” is defined in § 772.1 EAR as

  • any US citizen;
  • any permanent resident (especially Green Card holder), irrespective of where that person currently is;
  • any person of any nationality who resides in the US;
  • any person in the US;
  • any juridical person organized under the laws of the US, including foreign branches in the US.

An important thing to remember here: There is no definition of “US person” that is valid for all US legislation. The definition can vary depending on which US law is applicable. Business transactions with embargoed countries, for example, are governed by the Office of Foreign Assets Control (OFAC), which defines US persons differently than the EAR. The definition of the term “US person” must be checked separately for each law. Definitions of the term “US person” that differ from those of the EAR can be found, for example, in 31 CFR § 560.215 of the Iranian Transactions and Sanctions Regulations (ITSR) for business transactions with Iran.

Companies outside the US are generally organized under the applicable national law and not US law, so they are not US persons under the EAR. This is true even if such companies employ US persons, such as US citizens.

Companies outside the US should focus on US items. If the company’s product portfolio includes US items, it’s a good idea to identify them as such and classify them. This is the only way to ensure compliance with the provisions of US re-export control law for US items under the EAR.

Standarddatei

EAR99, CCL, ECCN, critical designated use, end-user, country of destination, ...?

The topic of US export controls is not exhausted yet. There is more to it, of course, and also includes the topics mentioned in this header. Are you ready to delve deeper? Then read on in the next article:

Exporting and re-exporting US items: What to consider

Scope of EAR: tips for running checks

The US Bureau of Industry and Security (BIS) offers a range of helpful tools on its website. The Exporter Portal offers technical FAQs and Decision Tree Tools to help with various checks such as:

  • CCL Order of Review
  • Specially Designed
  • STA
  • De minimis & Direct Product Rules
