Medical technology manufacturer ERBE Elektromedizin maps the entire shipping and warehouse process – from goods receipt, put-away, picking and packing, to loading and monitoring – with AEB.
Forward-looking logistics for medical technology manufacturer ERBE
IT support from AEB’s Warehouse Management
Warehouse management from push to pull, from tiny to massive
Warehouse management convenience and transparency for staff
Status monitoring and logistics performance indicators
More customer service through transparency
Summary, benefits, and outlook
For years, German medical technology company ERBE has achieved strong growth both at home and abroad. Exports currently account for some eighty percent of revenue. The structure that had evolved over the years was not equipped to fully meet these and other challenges.
The cornerstone of a new logistics center, built adjacent to the existing facility on the southern outskirts of Tübingen, was laid in February 2007. Production and logistics operations had to be maintained throughout the entire construction period. After thirteen months of construction, the new warehouse was ready for operations. It took just three days for ERBE to move into the new logistics center with its six storage areas and get up to production level. The nearly 3,000 square meters of floor space in the new logistics center accommodate the following:
The entire intra-logistical process—from goods receipt to stock put-away, from picking and stock removal to packing, from complete freight document preparation to loading—is mapped by the Shipping and the Warehouse Management software developed by AEB in Stuttgart. Standardization and automation were the benchmarks in planning and designing the IT architecture of the new logistics process. For ERBE Elektromedizin GmbH, automation means not only mechanized support but process support.
This support is ensured by:
One innovation that facilitates stock put-away and removal in the automatic small-parts storage area is the inclusion of both a laser-guided display and a monitor display. When an employee initiates stock removal during the picking process in the small-parts storage area, for example, movement orders are generated, and the material flow computer controls the transport of the tray to the appropriate picking bin. A laser beam points to the tray segment from which the goods are to be removed. A graphic display also indicates the right compartment on the monitor.
To avoid errors in the picking process, the picker first scans the handling unit from which the goods are to be removed, then the article to be removed, and finally the handling unit into which the article is placed for further transport to the packing station. AEB’s Warehouse Management also supports the picking process in the manual warehouses. The Warehouse Management software calculates the best route within the warehouse using transport chains and priorities stored in the master data. Employees receive route-optimized driving orders on the forklift control terminal in the high-rack storage area. In the other storage areas, handheld devices are used.
Scanners support the removal of the goods in all storage areas. The pull principle, already implemented in production processes as “kanban” control, is now applied to logistics—for example, through the installation of “pulling” packing stations that are mapped in the warehouse management system. While consolidating goods from the various storage areas at the packing stations, bottlenecks are avoided by triggering a picking order only after a line or location in the staging area shows the appropriate capacity. Picked goods—whether from the automatic small-parts storage, block storage or high-rack storage area—are now made available at the consolidation shelf or line originally defined for this consignment.
The employee sees the consignment’s consolidation bin on the handheld device through control and monitoring scans. The consignment volume and weight determine whether the merchandise must be brought to the staging area or to one of the ten lines. Following the system-supported check for completeness, the consignment is released for packing. The packer receives a corresponding alert in the packing station application. Data such as package type and package content and other information needed for the Shipping process is collected and administered at the consignment level. The packing process is “qualified”: Each article with a batch or serial number is scanned once more before being physically packed to make sure it is in the right consignment. This provides an extra layer of control against the errors of individuals in support of a system-wide zero-error strategy.
It also enhances traceability based on batch and serial number. Like the other consignment-specific documents, the package list is generated by the system during the process and printed and checked in the dispatch office, where it can then be added to the consignment as soon as the packing is complete. The electronic link through ATLAS to the customs administration office also helps shorten lead times in shipment processing. Integrated compliance screening, which automatically checks all ship-to and bill-to parties against EU and US sanctions lists, ensures that no consignment is sent out to anyone with suspected links to terrorism.
The Warehouse Management cockpit gives warehouse managers important information for planning and controlling the processes they oversee. For example:
The entire process is controlled and monitored by a system of indicators. All relevant process information — involved parties, lead times, consignment contents, consignment routes, Monitoring & Alerting information — is available for operational control, creating greater transparency in the process, enhancing the reliability and lowering the error rate.
By consistently tracking the relevant indicators, ERBE Elektromedizin GmbH is able to continuously increase logistical performance. End-to-end software support yielded logistical processes that were less individualized but more reliable and efficient. The consolidation bins before the packing area have proven to be both physically and logically critical to Shipping management.
It is essential to have a seamless transition of the picking results into the packing process. The aim is to achieve the current benefits of consistently consignment-based but manual picking by an employee through quick and error-free consolidation of the now fragmented picking process. This will be a critical success factor of the warehouse process, which is much more heavily reliant on a division of labor.
The system was designed with very robust support to offer users rapid resolutions when incorrect entries are made, or unpredictable inventory situations arise. The conscious selection of an integrated software package—in which warehouse, transport and export processes are mapped in a single environment—has paid off by reducing the number of interfaces.
In 2012, Erbe also implemented Monitoring & Alerting from AEB’s Supply Chain Collaboration Platform. The online application lets Erbe employees in the company headquarters and at its subsidiaries around the world see the status of any shipment at a glance. Erbe subsidiaries in Belgium or the United States can call up their own orders and see whether the goods have already been picked, packed, or issued. The status updates of the transport service providers that Erbe works with – DHL, FedEx, Kühne + Nagel, Transmed, etc. – are also integrated and visible in real time.
It’s not only the consignees who have access to more information: The “Performance Indicator” presents logistics managers with all key performance data at a glance, so they always know how many shipments went out in a given period and which percentage was on time. The logistics experts at Erbe wanted to bring greater transparency to the flow of goods – both in-house movements and shipments to customers – so they could act early to prevent possible delays. AEB’s Monitoring & Alerting now lets you quickly see if goods remain too long at a hub or an outbound delivery faces a possible delay. Information technology makes it possible to schedule and plan the direct shipment of goods to customers throughout Europe. Erbe has the capacity to respond quickly to any incidents and head off possible delays.
The customs department also benefits from having transparent export transactions. If a proof of export is not received on time, the case manager is notified by e-mail. Overall, both Erbe and its customers now benefit from end-to-end transparency throughout the process until the shipment arrives at its final destination.
ERBE Elektromedizin GmbH has responded to legal requirements and internal targets by reorienting itself and completely reorganizing its logistical processes within two years. The sales department has been relieved of organizational responsibilities and is now able to focus exclusively on customer contact, shipment releases and availability checks.
ERBE customers now benefit from faster and more reliable deliveries. And ERBE customers will enjoy more benefits in the future—as ERBE continues to shorten lead times, for example, by eliminating European logistical processing stages still in place to exploit further cost-cutting potential. In this way, logistics helps protect competitiveness. The quality of logistics is rising, meanwhile, as the risk of defects is lessened, which in turn decreases the number of costly returns. The implementation of a new logistics concept already enables faster, more efficient and more customer-centered processing while offering further potential for future developments.
